$598.95
Model 29 Heavy duty gaugeless single stage oxygen regulator is specifically designed for use in installations where rough handling of gas apparatus is commonplace. The color-coded Cylinder contents indicator and the delivery pressure calibration on the bonnet are easy to read.
• Heavy duty gaugeless Regulator designed for use in abusive conditions
• Easy-to-view color-coded Cylinder contents indicator
• Delivery calibration on the bonnet is easy-to-read
• Brass body and electroless nickel-plated zinc bonnet for longer service life
• Ergonomic ABS plastic knob for easy grip and precise adjustment
• No gauge
• One-piece encapsulated seat design with internal filter to protect the PTFE Teflon seat from particulate contamination
• Neoprene diaphragm for improved pressure control
• UL listed
| Adjusting Knob | ABS plastic |
| Body | Electroless nickel-plated |
| Bonnet | Electroless nickel-plated zinc die cast |
| Certification | CGA E-4, UL® listed |
| Cv | 0.17 |
| Delivery Pressure Range (PSIG) | 0 – 100 |
| Diaphragm | Neoprene |
| Duty | Heavy |
| Gas / Gas Service | Oxygen |
| Gauges | Gaugeless |
| Inlet Connection | CGA 540 |
| Maximum Inlet Pressure (PSIG) | 3000 |
| Outlet Connection | 9/16 in. – 18 RH |
| Outlet Fittings | 9/16 in. – 18 LH |
| Pressure Regulation PSIG/100 PSIG | 0.2 |
| Seat | PTFE Teflon® |
| Typical Application | Industrial applications |
| Warranty | 7 Years |
